WD-300A
Meetyou
842230
The Available Range:
Mineral water, drinks, beer, wine, medicine bottles’ group packing which doesn’t need bottom bray.
After packing, the products will become firm and more good-looking.
Characteristics:
It adopts the imported PLC programme automatic control. It has a stable function and precise control.
It has automatic functions like conveying materials, unscrambling, shrinking and cooling & design finalizing flow.
The film conveying adopts the imported transducer control in order to reach stepless speed conversion.
It adopts the advanced spiral wind circulating structure and three-layer heat insulation to save resources.
Besides, it uses the enhanced cooling and design finalizing passage which can make product packing finalize the design more quickly and easy to be stored and transported.
Main Technical Specifications
Overall Dimension (L×W×H) | 5050×3300×2100 |
Heat Shrinking Passage Dimension (L×W×H) | 3700×920×1800 |
Maximum Packing Dimension (L×W×H) | 600×400×350 |
Speed of Packing | 13-15 |
Height of Conveying Belt | 920 |
Power of Working Electricity | 380V 20KW Three-Phase and Five-Lines |
Working Pressure | 0.6-0.8Mpa |
